TRIPLE POINT PALISADE steel FENCING

Product Item：30004

Brand Name：CHIEFENCE

Certification：Q235

Model Number：30004

Materials：Q235

Type：Welded type

Treatment：Per-galvanized then PVC sprayed/painted Hot-dipped galvanized

Color：Ral6005 Green, Ral9010 White, Ral7021 Black grey, RAL9005Black ect

Warranty：10 years

Market：South Africa, Botswana, Zimbabwe, Zambia, Namibia, Tanzania, Nigeria, Congo, Ghana, Turkey, Algeria, Uganda, Mozambique

Payment Terms：TT,LC, Cash.

Packaging Details：1.Panel-Metal Pallet wrapped with cardboard plate and then wrapped with plastic film 2. Post- Wrapped with PP bags,then put on pallet ,wrapped with plastic film 3. Accessories- Carton 4. Customized pa

Delivery Time：Normally 20 days

Description

Palisade security fences are manufactured in two pale profiles, a "W" profile and a "D" profile.

Both are available in a wide range of training heads. These pale profiles can be offered in different thin thicknesses to suit different environments and safety requirements. It is recommended to use a thick and thin profile in areas where the fence is likely to be attacked.

Vertical stanchions can be provided in different thicknesses depending on the protection and the risk of Suffering from persistent attacks.

Palisade steel FENCING can provide a rigid fence system with a high level of protection at a reasonable cost and is available in galvanized or polyester coated finishes. Hoarding systems range from low security fencing to high security fencing, depending on the thickness and profile of steel specified and the fastening system.

PALISADE steel FENCING is offered in standard 2.75m wide panels for easy assembly on site. Manufactured in D or W profile, the top (single point, triple point, round) can be selected and is available in heights ranging from 0.9m to 4m, depending on the level of security required. If you require a fence height of 6 feet or less, we recommend using a round top alternative. This is due to an obvious security issue.

We can also supply pedestrian and vehicle gates to match the steel fence.

The Palisade security fence consists of steel posts with empty slots in between. The slits allow the wind to pass through, allow for a much stronger barrier than steel storage, and allow for a much more attractive look. Ideal for uneven floors.

PALISADE steel FENCING are available in a variety of heights and finishes, including galvanized and powder coated in blue, red, green, black or white.

You can improve security by choosing the triple point spikes at the top of each vertical post. You can provide extended functionality to add additional anti-climb devices such as barbed wire to properly and truly protect your facility.

PALISADE steel FENCING
The Palisade fence panel consists of a hot rolled steel section and a cold rolled steel section supplied for on-site assembly. Both underground and bolted applications are available.
PALISADE steel FENCING
When specifying a security fence, security should be a top priority. It is not recommended to use a pointed top bucket at a height lower than 1.8m in the Palisade fence system. For this height range, you must choose an alternate slim top or other fence style.

panel		W&D pale	Pale diatance	Cross rail	Post&IPE
high （M）	Standard width （M）			Angle &square
1.8	2.75	2.0-3.0	130-180mm	30x30mm	60x60mm
2.1		2.0-3.0	130-180mm	40x40mm	80x80mm
2.4		2.0-3.0	130-180mm	50x50mm	IPE 100x55mm
