Description
Welded wire mesh fencing
Our chiefence Welded wire mesh fencing also called “3D fence”, is made of high-quality Q195 low carbon steel wire and the surface treatment is excellent anti-corrosion coated, and it can ensure the fence can be used for a long time.
There are "V" shaped bends on the top, middle and bottom edges of the welded wire mesh fence panel, this not only makes the fence appearance more beautiful but also strengthens the fence and is not easy to destroy, the Welded wire mesh fencing consists of the 4mm welded wire mesh fence, fence pole and spider clamps with bolts and riv-nuts.
The Welded wire mesh fence popular bend method,
A: 100mm
B: 200mm
C: 200mm without regid wire
D: 100mm with 2 regid wire
|
Welded wire mesh fence sepecification |
|
|
Mesh size |
50*200mm/50*100mm |
|
Wire diameter |
4mm/5mm |
|
height |
630mm-2230mm |
|
width |
2300mm/2400mm / 2500mm / 2900mm |
|
Accessories |
Spider clips/plastic clamp/steel clamp with bolts and nuts |
|
Color |
All RAL colors available |
The Welded wire mesh fence have a variety of post options
|
Post options |
||||
|
option |
Size |
Thickness |
Fittings |
Type |
|
Square |
40*60mm |
1.2-2.0mm |
|
Common |
|
50*50mm |
1.2-2.0mm |
Common |
||
|
60*60mm |
1.2-2.5mm |
Common |
||
|
60*80mm |
2.0-2.5mm |
Strong |
||
|
I post |
70*44mm |
1.2-2.0mm |
|
Common |
|
Round tube |
48mm |
1.0-3.0mm |
|
Common |
|
60mm |
1.0-3.0mm |
Strong |
||
|
Peach Post |
50*70mm |
1.2mm |
|
Common |
|
70*100mm |
1.2mm |
Strong |
||
