Anti climb mesh fence with square post

Product Item：300056

Brand Name：Chiefence

Certification：ISO/Q195/HR2/BS-S185/ASTM A285M GR.B/SGS,CE/BS EN10244-2:2009 CLASS-D

Model Number：300056

Materials：Q195 or Q235

Type：high security fence

Treatment：Per-Galvanized with powder coating colors, Like green, yellow, black,

Color：Green RAL 6005 , White RAL 9010 , Black RAL 9005， Grey RAL 7021 , Other colours are available on request

Warranty：10 years

Market：South Africa, Botswana, Zimbabwe, Zambia, Namibia, Tanzania, Nigeria, Congo, Ghana, Turkey, Algeria, Uganda, Mozambique

Payment Terms：TT,LC, Cash.

Packaging Details：1.Panel-Metal Pallet wrapped with cardboard plate and then wrapped with plastic film 2. Post- Wrapped with PP bags,then put on pallet ,wrapped with plastic film 3. Accessories- Carton 4. Customized pa

Delivery Time：7-15 days/20' container, 10-25 days /40’container

Description

Anti climb mesh fence with square post

Anti climb mesh fence is also called 358 fence( 3"x0.5"x 8guage) also known as"prison mesh"or anti-climb fence,is a special fencing panel,

"358"comes from its measurements 3" x 0.5" x 8 gauge

which equates to .76.2mm x 12.7mm x 4mm

performance, durability and appearance,.

Anti-Cut: Robust wire and weld joints make cutting very difficult using a conventional bolt or wire cutters.

Anti-Climb: No toe or finger holds due to small mesh apertures.

Anti-climb fences are bespoke security products that create visual screens and protective barricades for properties needed to delay and thwart potential attacks. A distinctive feature of lattice crime fences is the manufacture of anti-limestone and anti-cut welded mesh. This makes it very difficult to build scaffolding on this fence, and the cutting tools needed to cut the heavy welded steel wires do not fit into the minimum mesh space.

Anti-Crime Welded Wire Mesh

Anti-Climb Fence is a unique perimeter security product with the visual control and balance of security needed to delay and thwart attacks. With this manufacturing method, it is very difficult to attach scaffolding or guardrails to this fence, and the cutting tools needed to cut the heavy steel wire do not easily fit into the minimum space of the opening of the trellis.

Anti climb mesh fence

Maintaining safe boundaries is the first line of defense against potential threats. Anti-climb security fencing is ideal for securing at-risk facilities or for protecting certain assets within existing assets.

The 4mm welded steel wire that forms each trellis panel provides an anti-climb fencing function, and each panel is attached to a continuously flanged steel post using non-removable shear nuts.

Material: Low Carbon Steel Wire, Galvanized Wire

Finished: Electric Galvanized, Hot Dipped Galvanized, Polyester Painting.

Polyester Painting Color: Any RAL Series Color ( Normal RAL6005-Dark Green,RAL9005-Black).

anti Climb Fence security fence
Fence	Panel Size	Section	O/A Length	Total number of fixings	Corners- 2 Clamp bars
Height	Height/Width	Section	O/A Length	Clamp bar	Corners- 2 Clamp bars
2.0	2007*2515	60x60x2.5mm	2700	7	14
2.4	2400 *2515	60x60x2.5mm	3100	9	18
3.0	2997 * 2515	80x80x2.5mm	3800	11	22
3.3	3302 * 2515	80x80x2.5mm	4200	12	24
3.6	3607*2515	100x60x3mm	4500	13	26
3.6	3607*2515	100x100x3mm	4500	13	26

LineWirex crosswire	HoleSize	Length	Height	BendingNo.	CommonColor	Surfacetreatment
4x3mm 4x4mm	76.2x12.7mm	2m 2.2m 2.4m 3m	1800mm	4	Green RAL 6005 Grey RAL 7016 Black RAL 9005	1.Hot-dipped galvanized after black wire welded 2.PVC coated after galvanized wire welded 3.PE coated after galvanized wire welded
			2000mm
			2200mm	4
			2400mm	4
			2800mm	5
			3000mm	5
